UV Mercury-Cure Ink

SKU:UV7000-1 ✔ Eco-friendly ✔ Quick-drying ✔ High-performance

Starcolor’s UV Mercury-Cure Ink is a high-performance UV printing ink engineered specifically for conventional mercury-lamp curing systems used in high-speed flexographic production.

Formulated to deliver fast curing response, exceptional film build and high gloss, this ink provides reliable adhesion across a wide range of substrates — including coated paper, BOPP, PET and varnished stocks — making it ideal for premium packaging, labels and flexible film applications.

Weight	Package	Unit-Price
5kg	1 bucket	$ 15.**
20kg	1 drum	$ 15.**
>100kg	>20 barrels	$ 14.**

Send Inquiry →

Position：Home > Products > UV Inks

Product Introduction

Starcolor UV Mercury-Cure Ink is formulated for high-speed printing lines that use traditional mercury-lamp UV curing systems. It delivers rapid cure response, strong adhesion across coated substrates and films, and a high-gloss finish suitable for premium packaging and labels.

Key Features & Benefits

Fast mercury-lamp curing

Stable polymerization at high line speeds

Strong adhesion

Excellent bonding on coated paper and synthetic films

High gloss & color density

Premium look for packaging applications

Chemical & scratch resistance

Enhanced durability for labels and flexible packaging

Optimized for flexo

Formulated to reduce ghosting and mottling on long runs

Low odor & stable runnability

Designed for production environments

Technical Snapshot

Product	UV Mercury-Cure Ink (Flexo )
Typical Viscosity (25°C)	800–1500 cps (adjustable by grade)
Curing Energy	Recommended 120–160 mJ/cm² (mercury lamp)
Recommended Print Speed	100–250 m/min (dependent on press & lamp)
Gloss	High
Shelf Life	6 months (sealed)

Available Colors

C, M, Y, K
Opaque & Bright Whites
Spot & Custom Pantone Colors (on request)

Compatible Substrates

Coated paperboard & art paper
BOPP, PET, PVC films
Varnished & pre-coated substrates
Synthetic paper

Why Choose Starcolor UV Mercury-Cure Ink

Starcolor's UV Mercury-Cure formulation is engineered for reliable curing performance on traditional mercury-lamp systems — including lower-energy or aged lamps. Compared with many standard UV inks, it offers improved adhesion on coated and film substrates, more consistent runnability on long production runs, and lower migration risk for surface-printed packaging.

Recommended Curing & Press Guidelines

Mercury lamp energy: 120–160 mJ/cm²
Best printing speed: 100–220 m/min (test per press)
Maintain lamp cleanliness and reflector condition for consistent cure
Substrate surface tension: recommended ≥ 38–42 dyn

Full Technical Specifications

Property	Typical Value / Range
Viscosity (25°C)	800–1500 cps (Brookfield)
Density	approx. 1.05–1.20 g/cm³
Curing Energy	120–160 mJ/cm² (mercury lamp recommended)
Cure Speed	Up to 100–180 m/min (press & lamp dependent)
Gloss	High (instrument measured)
Adhesion	5B (on recommended substrates)
Solvent Resistance	Good after full cure
Storage	Store 5–25°C, avoid direct sunlight

Notes: Values shown are typical and for guidance only. Final suitability should be confirmed by on-press testing with your specific substrate and curing system.

Frequently Asked Questions

Q: Is UV Mercury-Cure Ink compatible with LED UV curing?

A: No. This product is engineered for mercury-lamp UV curing systems and is not suitable for LED UV wavelengths.

Q: Which printing methods is this ink suitable for?

A: Optimized for flexographic printing. Consult us for retrofits or specialty press configurations.

Q: Can I order custom Pantone or spot colors?

A: Yes — we offer spot color matching and custom formulations. Lead time and MOQ apply.

Q: What safety certifications or compliance does it meet?

A: The formulation is free of heavy metal pigments and restricted solvents. For food-contact or regulatory statements, request specific compliance documentation.

Q: What sample sizes are available?

A: Trial samples (250–500 mL) and production-size drums are available. Contact sales for logistics and pricing.

Contact Us

Our engineers are ready to help you optimize your ink viscosity, pH control, and adhesion for high-speed flexo presses. Tell us about your substrate, and we'll provide a tailored quote within 24 hours.
